Product Name: ATST Series Servo Automatic Wire Reeler, Wire Reel Stand, Copper-clad Aluminum Winding Machine, Winding Machine, General Winding Machine.
The servo wire feeder adopts an active wire feeding method to replace the traditional passive one. It achieves a stable tension value by controlling the motor speed and is equipped with a tension feedback stabilization system, which can automatically maintain a stable and balanced tension. During the wire feeding process, the tension remains constant from a full spool to a small spool. Compared with traditional mechanical wire feeders, it reduces the frequency of tension adjustment and improves product quality.
Selection Reference Table
| Model | Reference Wire Diameter | Tension Scope | ||
| ATST3-100 | Φ0.03-Φ0.12 | 3-100 | ||
| ATST3-300 | Φ0.06-Φ0.21 | 20-300 | ||
| ATST3-800 | Φ0.09-Φ0.35 | 50-800 | ||
| ATST4-100 | Φ0.03-Φ0.12 | 3-100 | ||
| ATST4-300 | Φ0.06-Φ0.21 | 20-300 | ||
| ATST4-800 | Φ0.09-Φ0.35 | 50-800 | ||
Structural diagram of the line laying device
Schematic diagram of the external structure
Announcements
1. Do not touch the tension rods when the machine is in operation.2. Prevent the line feeder from falling and avoid being subjected to strong impacts that may cause damage.
3. The winding speed should not exceed 5 meters per second (subject to the requirements of the actual model. If there are special needs, you can contact our company for customization). The startup speed of the winding machine should not exceed 1 meter per second.
4. When the enameled wire passes through the line pulley, it is necessary to check whether the enameled wire is hung on each guide wheel to ensure that the guide wheels can rotate normally during operation without getting stuck.
5. The line pulley and tension rods are wear-prone parts. Even within the warranty period, if the above-mentioned parts are worn and need to be replaced, the corresponding costs still need to be paid. The cost standard will be based on the actual quotation of our factory at the time of replacement.
